The Institute for Forming Technology and Forming Machines has a well-equipped experimental area. Various machines and apparatus are available to the staff for carrying out experimental investigations. Furthermore, the employees have access to powerful hardware and software for the simulation and numerical investigation of forming processes. In the following, the institutes own experimental machines and experimental devices are listed and described.
The Institute for Forming Technology and Forming Machines has a well-equipped experimental area. Various machines and apparatus are available to the staff for carrying out experimental investigations. Furthermore, the employees have access to powerful hardware and software for the simulation and numerical investigation of forming processes. In the following, the institutes own experimental machines and experimental devices are listed and described.
Presses
- Hydraulic Double-Column press of the company Dunkes Typ HD 250
- Hydraulic press Hydrap HPDZb 63
- Spindle press - Weingarten Type PSR 160
- Eccentric press - Eumuco Type SP30a
- Spindle press - Lasco Type SPR 500
- Hydraulic press - Schirmer + Plate
- Multi-axis powder press - SMS Meer HPM 200 E2
- Double eccentric press Helmerding
- Eccentric press Haulick+Roos RSH 630-1000
- Automatic punching press with servo drive Schuler MSC 2000
- Rotary Swaging Machine Felss Genaration E
Testing machines
- Strip drawing machine with and without redirection
- Universal sheet metal testing machine Roell+Korthaus AMSLER
- Wear test stand
- Fatigue testing machine RUMUL TESTRONIC
- Forming simulator Gleeble 3800
- Hydraulic bulge test in accordance with DIN EN ISO 16808
- Servo-hydraulic forming simulator (Plastometer)
- Erichsen universal sheet testing machine with ARAMIS (GOM company)
- Tensile testing machine S100/ZD DYNAMESS
- Quenching and deformation dilatometer DIL 805A/D+T of the company Bähr
- Triboindenter Hysitron TI 950
Metrology
- GOM-Atos 2 400
- Keyence VR-3200 Profilometer
- Surface measuring station T8000-RC, Fa. Jenoptik/HOMMEL-ETAMIC
- Acoustic camera Bionic M-112 (Fa. CAE Software & Systems)
- Displacement measurement system GOM Pontos HS
- X-ray diffractometer XSTRESS X3000 G2
